Gas Fryer
Contact
- Two nickel plated oblong wire mesh baskets
- One nickel plated tube rack
- One drain extension
- Built-in heat deflector
- 6” adjustable legs
- Original : USA
CONSTRUCTION
- Welded 16 gauge stainless steel tank with a super smooth machine finish ensures easy cleaning
- Long lasting baffles are mounted in the heat exchange tubes to provide maximum heating and combustion efficiency
- Standing pilot light design provides a ready flame when heat is required
- Cabinet is constructed of stainless steel front and door with galvanized sides and back
CONTROLS
- Thermostat maintains temperature between 200°(93°C) and 400°F(204°C)
- Integrated gas control valve acts as a manual and pilot valve, automatic pilot valve, gas filter, pressure regulator and automatic main valve
- Gas control valve prevents gas flow to the main burner until pilot is established and shuts off all the gas flow automatically if the pilot flame goes out
- Temperature limit automatically shuts off all gas flow if the fryer temperature exceeds 450°F(232°C)
OIL CAPACITY
35-40 pounds (20.8kg) – Model GF-90 (18.5-23 Liter)
45-50 pounds (21.4kg) – Model GF-120 (21.3-25 Liter)
65-70 pounds (33.6kg) – Model GF-150 (31-37 Liter)
